Yaftech Motor
1 / 5
| Item NO. | Prop | Throttle | Volts (V) | Amps (A) | Watts (W) | Speed (RPM) | Thrust (g) | Efficiency (g/W) | Temp (℃) |
|---|---|---|---|---|---|---|---|---|---|
| D3536-1450KV | APC9x6 | 40% | 11.14 | 11.14 | 143.6 | 682 | 7838 | 4.7 | 66.8℃ |
| 50% | 12.82 | 15.20 | 194.9 | 843 | 8711 | 4.3 | |||
| 60% | 12.76 | 19.14 | 244.2 | 997 | 9446 | 4.1 | |||
| 70% | 12.68 | 23.39 | 296.6 | 1150 | 10112 | 3.9 | |||
| 80% | 12.53 | 31.06 | 389.2 | 1402 | 11054 | 3.6 | |||
| 90% | 12.34 | 40.18 | 495.8 | 1669 | 11932 | 3.4 | |||
| 100% | 12.23 | 45.45 | 555.9 | 1788 | 12301 | 3.2 | |||
| D3536-1450KV | APC11x7 | 40% | 12.68 | 11.83 | 150.0 | 747 | 7177 | 5.0 | 65.6℃ |
| 50% | 12.54 | 16.31 | 204.5 | 940 | 7971 | 4.6 | |||
| 60% | 12.37 | 20.86 | 258.0 | 1089 | 8624 | 4.2 | |||
| 70% | 12.28 | 26.79 | 329.0 | 1314 | 9296 | 4.0 | |||
| 80% | 12.14 | 35.38 | 429.5 | 1510 | 10184 | 3.5 | |||
| 90% | 11.86 | 45.13 | 535.2 | 1787 | 10876 | 3.3 | |||
| 100% | 11.84 | 51.45 | 609.2 | 1884 | 11260 | 3.1 |
Providing propulsion system solutions for UAVs with advanced technology, specializing in Motors, ESCs (Electronic Speed Controllers), and Servos. Our products have passed ISO 9001:2015, which is widely used for aerial photography, industrial, agricultural, and commercial applications, obtaining a high reputation for high quality. We have strong R&D ability and confidence to provide professional OEM/ODM RC solutions for all customers since our technical team comes from famous branded enterprises and with rich experience in the RC industry. We have been focused on all series of flight control systems, brushless speed controllers/ESC, FOC speed controllers (ESC), outrunner brushless motors, hall brushless motors and photography applications, supplying high-quality RC solutions for many famous brands. Taking customer demands as the orientation and the improvement of product performance and quality as the goal of bringing more satisfying products to customers. We also offer OEM/ODM services to meet various demands from customers. We would like to grow up with you and gain mutual benefits.
